DALI Dimming LED driver, DALI Dimming LED controller, DALI Dimming LED dimmer - Euchips

Tunable White RGB DALI Panel DALI-P05

Tunable White RGB DALI Panel DALI-P05 Features · Complies with DALI protocol standard IEC62386 · DALI panel supports brightness, Tunable White, color adjustment · Simple and fashionable appearance, beautiful and easy to operate · Used in study, bedroom, dining room, bar and other occasions requiring dimming control · Support DALI group/scene control Technical Parameters Model DALI-P05 Input Voltage Supplied Via Dali Bus Control Signal DALI Signal Group 3 Scene 4 DALI Protocol IE...

detail
DALI Tunable White Knob Dimmer DALI-CCT

DALI Tunable White Knob Dimmer DALI-CCT Technical Parameters Model DALI-CCT Input Voltage 110-240V AC Output Current 150mA Output Signal DALI signal(Single address/Group/broadcast) Working temp. -10℃~45℃ Relative humidity 20~90%RH N.W. 132g G.W. 182g Dimension(mm) 86×86×57.5

detail
DALI Rotary Knob Dimmer DALI-R01CCT

DALI Rotary Knob Dimmer DALI-R01CCT Features 1. Follow DALI IEC62386 DT8 standard protocol 2. DALI knob supports brightness and color temperature adjustment 3. Support single-address, multicast and broadcast control modes 4. It has the function of power saving 5. ABS high flame retardant material, high temperature resistance and impact resistance 6. Used in study, bedroom, dining room, bar and other occasions requiring dimming control 7. Suitable for installation in European specifications a...

detail
DALI Tunable White Knob Dimmer DALI-P40D

DALI Tunable White Knob Dimmer DALI-P40D Model DALI-P40D Input Voltage 110-230V/AC 50-60Hz Output Current 150mA (Bus power supply)A Output Signal DALI signal (Group/broadcast/Scene/ Tunable White) Working temp. -10℃~45℃ Power ≤5W Relative humidity 20~90%RH N.W. 165g G.W. 185g Dimension(mm) 86×86×45

detail
DALI Analog Signal Amplifier DALI-A01

DALI Analog Signal Amplifier DALI-A01 Features · For amplification of Dali signal drive capability. · Signal can be amplified to 5 levels multiple times · Adopt high-quality amplifying devices, with output signal capacity up to 300M · It is mainly used in situations where the output drive capacity of the main controller is insufficient Technical Parameters Model DALI-A01 Output Accuracy Channels 1 Voltage 9.5-22.5vDC Input Voltage 9.5-22.5vDC Signal DALI signal Others Dimensi...

detail
200-240VAC DALI Signal Amplifier DALI-A02

200-240VAC DALI Signal Amplifier DALI-A02 Features · For amplification of Dali signal drive capability. · Signal can be amplified to 4 levels multiple times · Adopt high-quality amplifying devices, with output signal capacity up to 300M · It is mainly used in situations where the output drive capacity of the main controller is insufficient Technical Parameters Model DALI-A02 Output Accuracy Channels 1 Voltage 9.5-22.5VDC Input Voltage 220-240VAC Signal DALI signal Others Dimensio...

detail
90-240VAC 5A*2ch DALI Relay DALI-T02

90-240VAC 5A*2ch DALI Relay DALI-T02 Features · Follow DALI IEC62386 standard protocol · Maximum support 5A*2 channel current · Wide voltage supply · Connected to DALI Bus, occupies 2 address, the address can be changed · Support grouping, scene editing, · Support two mounting modes: guide rail and screw fixation Technical Parameters Model DALI-T02 The input voltage 90-240 v AC Input frequency 50/60Hz Maximum switching current 5A*2CH Communication protocol Standard DALI Agreement ...

detail
220-240VAC 250mA*1ch DALI Master Controller DALI-130

Features 1. Meet DALI Protocol IEC62386 2. Output current up to 250mA Max 3. Support two installation methods of rail and screw fixing 4. Support over current protection 5. LED indicator light indicate status Technical Parameters Item DALI-130 Input Voltage 220-240VAC Input Frequency 50/60Hz Output Voltage 16V+5% Output Current 250mA Output Power 4W Working temp -20-50℃ Net Weight 71g Gross Weight 105g Product size 111*35*67mm（L*W*H） Packing size 354*234*232mm（L*W*H...

detail
DALI Master Controller DALI-200

DALI Master Controller DALI-200 Features 1. Meet DALI Protocol IEC62386 2. Automatically check equipments accessible to master 3. Automatically allocate short addresses according to DALI Protocol 4. Support re-addressing of all equipments 5. Support operations of broadcast, single or group addresses controlling on equipments 6. Able to set or read all the parameters in the parameter chart of DALI Protocol 7. Able to set or read by groups and scenes 8. Reserve debug command of DALI Protocol Te...

detail
12-20VDC 2mA DALI group-scene controller DALI-GSC-4

12-20VDC 2mA DALI group-scene controller DALI-GSC-4 Feature 1. Designed to comply with IEC60929/62386 2. Choose group or scene mode via DIP switch 3. Can individually control max.4 groups or scenes 4. Can dim up/down, on/off of any group on the panelㄗOnly for group modeㄘ 5. Can choose different scenesㄗOnly for scene modeㄘ 6. Power supply via DALI bus Technical Parameter Product Name 12-24VDC 2mA DALI group-scene controller Model DALI-GSC-4 Power supply Via DALI signal line Input ...

detail
DALI Relay Switch Controller DALI-T01

DALI Relay Switch Controller DALI-T01 Product features 1. Follow DALI IEC62386 standard protocol 2. The maximum current of a single channel is 10A 3. Wide voltage supply 4. Connected to DALI Bus, occupies 1 address, the address can be changed 5. Support grouping, scene editing 6. Support two mounting modes: guide rail and screw fixation Technical Parameters Model DALI-T01 Input voltage 90-240VAC Input frequency 50/60Hz Maximum switching current 10A Communication protocol Standard D...

detail
EU-BUS To DALI Gateway EUG-DALI

EU-BUS To DALI Gateway EUG-DALI In the EU-BUS system, the user can control the equipment complying with DALI standard protocol via EUG-DALI gateway. The user can assign（including reassign, extent allocation） the address for DALI equipment, and can set group, scene, the switch-on brightness, the minimum brightness, the maximum brightness, fadetime. In addition, the user can know the state of DALI equipment via PC software or information set in advance. Features 1. Assign（including reassign,...

detail
