0-10V/1-10V Dimming LED driver, 0-10V/1-10V Dimming LED controller, 0-10V/1-10V Dimming LED dimmer - Euchips

60-80W 0-10V CC Dimming Driver ARC DI 60-80 W M Series

60-80W 0-10V CC Dimming Driver ARC DI 60-80 W M Series Features · Supply Voltage 108-382Vac · Great Surge Immunity 2.5k(ringwave) · 50000Hour Life @ Tc=90℃ · 5Year Warranty@Tc<=90℃ · ±5% Output Current Accuracy · 0-10V/DIP Dimmable · UL Class P, Class 2 · Safety according to UL8750 & UL 1310 Model No. InputVoltage (VAC) Input Current (A) PF Output Voltage (VDC) MAX Output power (W) MAXIout(mA) Eff(Max) Life at Tc 90℃(h) ARC-DI-80I2100-UNV-DI-M 120-277 0.90(Max) 0.90 24-38 80 2...

detail
60-96W 0-10V CC Dimming Driver ARC DI 60-96 W S Series

60-96W 0-10V CC Dimming Driver ARC DI 60-96 W S Series Features · Supply Voltage 108-382Vac · Great Surge Immunity 2.5k(ringwave) · 50000Hour Life @ Tc=90℃ · 5Year Warranty@Tc<=90℃ · ±5% Output Current Accuracy · 0-10V/DIP Dimmable · UL Class P, Class 2 · Safety according to UL8750 & UL 1310 Model No. InputVoltage (VAC) Input Current (A) PF Output Voltage (VDC) MAX Output power (W) MAXIout(mA) Eff(Max) Life at Tc 90℃(h) ARC-DI-96I3000-UNV-DI-S 120-277 1.10(Max) 0.90 24-32 96 3...

detail
60-96W 0-10V CC Dimming Driver ARC DI 60-96 Wx2 L Series

60-96W 0-10V CC Dimming Driver ARC DI 60-96 Wx2 L Series Features · Supply Voltage 108-305Vac · Great Surge Immunity 2.5k(ringwave) · 50000Hour Life @ Tc=90℃ · 5Year Warranty@Tc<=90℃ · ±5% Output Current Accuracy · 0-10V/DIP Dimmable · UL Class P, Class 2 · Safety according to UL8750 & UL 1310 Model No. InputVoltage (VAC) Input Current (A) PF Output Voltage (VDC) MAX Output power (W) MAXIout(mA) Eff(Max) Life at Tc 90℃(h) ARC-DI-96X2-I3000-UNV-DI-L 120-277 2.20(Max) 0.90 ...

detail
Electronic LED Driver ARC EM 0525 UNV P2

Electronic LED Driver ARC EM 0525 UNV P2 Features · Suit for 8W to 100W lamp with external led driver. · Used with LiCoMnNi02 battery. · 18-50VDC output. · LED emergency converter that can transfer standard LED · fitting into emergency LED fitting. · Accessary test switch and charge indicator. Model No. Input voltage Ouput voltage/power (Emergency model) Battery pack Duration (E.M mode) ARC-EM-0525-UNV-P2/05 100-277Vac 50-60Hz 18-50V 5W LiCoMnNiO2 11.1V,2Ah,22.2Wh 90minutes ARC-EM-052...

detail
96W 0-10V CC Driver ARC-DI-96X2-I1920-MUV-D1S-LS

96W 0-10V CC Driver ARC-DI-96X2-I1920-MUV-D1S-LS Features · Universal AC Input Voltage(120-347VAC) · Metal sheet case · One isolated 0-10V dimming interface · Flicker free, excellent camera compatibility · Dual Output, Class2, Class P · Operating temperature: -20℃~+50℃ · Comply with IEEE1789, UL8750 · Programmable Output current(1mA step) Dim to off · Aux power, 12V/200mA · ANSI C62.41 Category B 6kV Model List Model NO. Rated Input Voltage Max Output power Default Output Current O...

detail
