  • 0-10V Tunable White Dimmer Walldim203

    0-10V Tunable White Dimmer Walldim203

    0-10V Tunable White Dimmer Walldim203   Model WALLDIM203 Product No. 403400020201 Input Voltage 110-240V AC 50-60Hz Output Current 2CH×50mA Output Signal 1-10V×2CH Working temp. -10℃~45℃ Relative humidity 20~90%RH N.W. 127g G.W. 152g Dimension(mm) 86×86×57.5
  • 0-10V Rotary Knob Panel Walldim204

    0-10V Rotary Knob Panel Walldim204

    0-10V Rotary Knob Panel Walldim204 Features · Support RS485 communication mode. · Direct control of the corresponding device through the key switch. · The scenario mode can be realized by connecting to a third party gateway Technical Paramaters Input Voitage、Frequency Range(Hz) 100-242V~, 50/60Hz Standby power ≤1W Storage Temp. -25℃~+70℃ Working Temp. -10℃~+45℃ Working Humidity ≤95RH ( No condensation) Output control method 0-10V
  • 12-24VDC 10A*1ch CV 0-10V Dimmer DIM-S1L10V-0

    12-24VDC 10A*1ch CV 0-10V Dimmer DIM-S1L10V-0

    12V 24V 10A 0-10V LED Constant Voltage Dimmer DIM-S1L10V-0 feature 1.?Support a variety of analog dimming signal; 2. Support the short circuit, over-current protection and alarm function; 3.?Support minimum brightness up-regulation function; 4. Support dimmer curve selection function; 5.?More than kinds of functions can be selected by switch,please take the switch function tables as reference; 6.F unction default setting is: 0-10V, 0V 100% output?Log Dimming Curve, Mini brightness no up-...
  • 12-24VDC 8A*2ch CV 0-10V Dimmer DIM-S2L8V-0

    12-24VDC 8A*2ch CV 0-10V Dimmer DIM-S2L8V-0

    12-24VDC 0-10V analog constant voltage led dimmer DIM-S2L8V-0 Feature 1. Support 3-in-1 dimming function(0-10V /1-10V active signal, Adjustable resistance, PWM) 2. Support dimming mode selection 3. Support the short circuit, over current protection and alarm function 4. Logarithmic dimming curve 5. Built-in CCT adjust mode, the user can adjust color temperature without changing the output power 6. For adjusting the brightness/ color temperature of LED strip Technical Parameter Product Name...
  • 12-24VDC 5A*3ch CV 0-10V Dimmer DIM116

    12-24VDC 5A*3ch CV 0-10V Dimmer DIM116

    12V 24VDC 3 Channels Constant Voltage Dimmer DIM116 Feature 1. Analog Signal driver, receive DC0-10V dim signal. 2. RGB three channels output, Max.5A per channel. 3.?It is applicable to various LED modules Technical Parameter   Product Name 12V 24VDC 3 Channels Constant Voltage Dimmer Item DIM116 Input voltage DC12-24V Input & output channel 3 channel, Max.5A per channel Output power 12V≒180W; 24V≒360W Size 165(L)X39(W)X26(H) mm Weight 260g
  • 12-24VDC 15A*1ch CV 1-10V Dimmer DIM119

    12-24VDC 15A*1ch CV 1-10V Dimmer DIM119

    12-24VDC 1-10V Constant Voltage Dimmer DIM119 Feature 1. Single channel constant voltage output. 2. Support 3-in-1 dimming mode(1-10V active signal, adjustable resistance, PWM) 3. Dimming range from 0.1-100%. 4. 100% output when no dimming signal input. 5. PWM digital dimming, no later LED color rendering index 6. Suitable for indoor LED lighting application. 7. Compatible with various of interfaces of the branded lighting control systems. Technical Parameter Model DIM119 Output Voltage ...
  • 12-24DC 15A*1ch CV 0-10V Dimmer Multidim-15V-0

    12-24DC 15A*1ch CV 0-10V Dimmer Multidim-15V-0

    12V 24V DC 1 Channel Constant Voltage Dimmable Driver Multidim-15V-0 This is a multi-functional LED dimmer, dimming mode, dimming curve, min brightness level all can be selected by dip switch.   Product Name: 12V 24V DC 1 Channel Constant Voltage Dimmable Driver ModelㄩMultidim-15V-0 Input Voltageㄩ DC12/24V Loadable current 15A Material ABS+PC Output Powerㄩ 180W/12V, 360W/24V Working Tempㄩ -35⊥ㄜ55⊥ Packing Sizeㄩ L167℅W52℅H24(mm) Protection(with warring led) Short-cir...
  • 0-10V Analog Signal Amplifier EUC601

    0-10V Analog Signal Amplifier EUC601

    0-10V Analog Signal Amplifier EUC601 Features Amplify driving ability of 0-10V signal, or convert PWM, passive signal to 0-10V signal Support 0-10V active signal, resistance/passive signal, and PWM signal High quality amplifier, output current of 200mA Used for the situation that the main controller’s driver ability isn’t enough Technical Parameters Model EUC601 Output Accuracy Channels 1 Voltage 0-10VDC Current 200mA Input Voltage 15-48VDC Signal 0-10V active signal, resistance...
  • 0-10V Analog Signal Amplifier EUC602

    0-10V Analog Signal Amplifier EUC602

    0-10V Analog Signal Amplifier EUC602 Features Amplify driving ability of 0-10V signal, or convert PWM, passive signal to 0-10V signal Support active and passive 0-10V color temperature (adjustable resistance) and PWM signal input High quality amplifier, output current of 150mA Used for the situation that the main controller’s driver ability isn’t enough Technical Parameters Model EUC602 Output Accuracy Channels 2 Voltage 0-10VDC Current 150mA Input Voltage 200-240VDC Signal 0-10V...
  • 5-23W 0-10V CC Dimming Driver ARC 5-23 W MB Series

    5-23W 0-10V CC Dimming Driver ARC 5-23 W MB Series

    5-23W 0-10V CC Dimming Driver ARC 5-23 W MB Series Features · Supply Voltage 108-382Vac · Great Surge Immunity 2.5k(ringwave) · 50000Hour Life @ Tc=90 ℃ · 5Year Warranty@Tc<=90 ℃ · ±5% Output Current Accuracy · 0-10V/DIP Dimmable · UL Class P, Class 2 · Safety according to UL8750 & UL 1310 Model No. InputVoltage (VAC) Input Current (A) PF Output Voltage (VDC) MAX Output power (W) MAXIout(mA) Eff(Max) Life at Tc 90℃(h)  ARC-DI-231700-UNV-DI-MB  120-277  0.26(Max)  0.90  24-32  23  ...
  • 15-50W 0-10V CC Dimming Driver ARC DI 15-50 W R Series

    15-50W 0-10V CC Dimming Driver ARC DI 15-50 W R Series

    15-50W 0-10V CC Dimming Driver ARC DI 15-50 W R Series Features · Supply Voltage 108-382Vac · Great Surge Immunity 2.5k(ringwave) · 50000Hour Life @ Tc=90℃ · 5Year Warranty@Tc<=90℃ · ±5% Output Current Accuracy · 0-10V/External Switch / Dimmable · UL Class P, Class 2 · Safety according to UL8750 & UL 1310 Model No. InputVoltage (VAC) Input Current (A) PF Output Voltage (VDC) MAX Output power (W) MAXIout(mA) Eff(Max) Life at Tc 90℃(h) ARC-DI-50I1400-UNV-DI-R 120-277 0.60(Max) 0.9...
  • 22-60W 0-10V CC Dimming Driver ARC DI 22-60 W P Series

    22-60W 0-10V CC Dimming Driver ARC DI 22-60 W P Series

    22-60W 0-10V CC Dimming Driver ARC DI 22-60 W P Series Features · Supply Voltage 108-382Vac · Great Surge Immunity 2.5k(ringwave) · 50000Hour Life @ Tc=90℃ · 5Year Warranty@Tc<=90℃ · ±5% Output Current Accuracy · 0-10V/DIP Dimmable · UL Class P, Class 2 · Safety according to UL8750 & UL 1310 Model No. InputVoltage (VAC) Input Current (A) PF Output Voltage (VDC) MAX Output power (W) MAXIout(mA) Eff(Max) Life at Tc 90℃(h) ARC-DI-60I1800-UNVDI-P 120-277 0.76(Max) 0.90 24-33 60 1800...
