0-10V/1-10V Dimming LED driver, 0-10V/1-10V Dimming LED controller, 0-10V/1-10V Dimming LED dimmer - Euchips

25W 450/500/550/600mA Triac & 0-10V CC Driver CUP25AT-1WMC(o)

25W 450/500/550/600mA Triac & 0-10V CC Driver CUP25AT-1WMC(o) CUP25AT-1WMC(o) is a constant current mode output LED driver. This driver can be controlled by external signal Phase-Cut ,0-10V to achieve a smooth dimming effect. Features · Comply With UL8750/CSA-22.2 No.250.13 Safety Regulations · All material to be ROHs compliant to Directive 2011/65/EU and (EU)2015/863 · Class P, Class 2 · 5 Years Warranty (Life expectancy of 50,000h at tc≤75°C) · Comply With FCC Part15 Class B (@120Vac in...

detail
34W 650/700/750/800mA Triac & 0-10V CC Driver CUP34AT-1WMC

34W 650/700/750/800mA Phase-cut & 0-10V CC Driver CUP34AT-1WMC CUP34AT-1WMC is a constant current mode output LED driver. This driver can be controlled by external signal Phase-Cut ,0-10V to achieve a smooth dimming effect. Features · Comply With UL8750/CSA-22.2 No.250.13 Safety Regulations · All material to be ROHs compliant to Directive 2011/65/EU and (EU)2015/863 · Class P, Class 2 · 5 Years Warranty (Life expectancy of 50,000h at tc≤75°C) · Comply With FCC Part15 Class B (@120Vac inpu...

detail
38W 750/800/850/900mA Triac & 0-10V CC Driver CUP38AT-1WMC(o)

38W 750/800/850/900mA Triac & 0-10V CC Driver CUP38AT-1WMC(o) CUP38AT-1WMC(o) is a constant current mode output LED driver. This driver can be controlled by external signal Phase-Cut ,0-10V to achieve a smooth dimming effect. Features · Comply With UL8750/CSA-22.2 No.250.13 Safety Regulations · All material to be ROHs compliant to Directive 2011/65/EU and (EU)2015/863 · Class P, Class 2 · 5 Years Warranty (Life expectancy of 50,000h at tc≤75°C) · Comply With FCC Part15 Class B (@120Vac in...

detail
40W 850/900/950/1000mA Triac & 0-10V CC Driver CUP40AT-1WMC

40W 850/900/950/1000mA Phase-cut & 0-10V CC Driver CUP40AT-1WMC CUP40AT-1WMC is a constant current mode output LED driver. This driver can be controlled by external signal Phase-Cut ,0-10V to achieve a smooth dimming effect. Features · Comply With UL8750/CSA-22.2 No.250.13 Safety Regulations · All material to be ROHs compliant to Directive 2011/65/EU and (EU)2015/863 · Class P, Class 2 · 5 Years Warranty (Life expectancy of 50,000h at tc≤75°C) · Comply With FCC Part15 Class B (@120Vac inp...

detail
10W 120-350mA Triac & 0-10V CC Driver PUP10AT-1WPC

10W 120-350mA Triac & 0-10V CC Driver PUP10AT-1WPC PUP10AT-1WPC is a constant current mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, 0-10V to achieve a smooth dimming effect. Features · Single channel output, output current can be selected by software • Compatible with TRIAC (forward-phase or leading-edge), ELV (reverse-phase or trailing-edge) and 0–10 V dimmers • TRIAC and ELV dimming at 120 Vac only • Class 2 power supply • Protections: ...

detail
15W 280-500mA Triac & 0-10V CC Driver PUP15AT-1WPC

15W 280-500mA Triac & 0-10V CC Driver PUP15AT-1WPC PUP15AT-1WPC is a constant current mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, 0-10V to achieve a smooth dimming effect. Features · Single channel output, output current can be selected by software • Compatible with TRIAC (forward-phase or leading-edge), ELV (reverse-phase or trailing-edge) and 0–10 V dimmers • TRIAC and ELV dimming at 120 Vac only • Class 2 power supply • Protections: ...

detail
20W 350~700mA Triac & 0-10V CC Driver PUP20AT-1WPC

20W 350~700mA Triac & 0-10V CC Driver PUP20AT-1WPC PUP20AT-1WPC is a constant current mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, 0-10V to achieve a smooth dimming effect. Features · Single channel output, output current can be selected by software • Compatible with TRIAC (forward-phase or leading-edge), ELV (reverse-phase or trailing-edge) and 0–10 V dimmers • TRIAC and ELV dimming at 120 Vac only • Class 2 power supply • Protections: ...

detail
30W 500-1050mA*1ch Triac & 0-10V CC Driver PUP30AT-1WPC

30W 500-1050mA*1ch Triac&0-10V CC Driver PUP30AT-1WPC PUP30AT-1WPC is a constant current mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, 0-10V to achieve a smooth dimming effect. Features · Single channel output, output current can be selected by software • Compatible with TRIAC (forward-phase or leading-edge), ELV (reverse-phase or trailing-edge) and 0–10 V dimmers • TRIAC and ELV dimming at 120 Vac only • Class 2 power supply • Protection...

detail
40W 800-1200mA Triac & 0-10V CC Driver PUP40AT-1WPC

40W 800-1200mA Triac & 0-10V CC Driver PUP40AT-1WPC PUP40AT-1WPC is a constant current mode output LED driver. The driver supports leading edge (Triac) and trailing edge (ELV) dimmer, 0-10V to achieve a smooth dimming effect. Features · Single channel output, output current can be selected by software • Compatible with TRIAC (forward-phase or leading-edge), ELV (reverse-phase or trailing-edge) and 0–10 V dimmers • TRIAC and ELV dimming at 120 Vac only • Class 2 power supply • Protections:...

detail
60W 24VDC Triac & 0-10V CV Driver MUP60AT-1W24V

60W 24VDC CV Driver MUP60AT-1W24V MUP60AT-1W24V is a constant voltage mode output LED driver. This driver can be controlled by external signal Phase-Cut ,0-10V to achieve a smooth dimming effect. Features ·Single channel constant voltage output,2.5A Max ·Wide input voltage of 120VAC ~ 277VAC input voltage of 120VAC ~ 277VAC ·Dimming range of 0.5-100%, and dimming effect smooth, no flicker ·100% output when no dimming signal input, can be used as normal power supply ·Protection: Over load; sho...

detail
96W 24VDC Triac & 0-10V CV Driver MUP96AT-1W24V

96W 24VDC Phase-cut & 0-10V CV Driver MUP96AT-1W24V MUP96AT-1W24V is a constant voltage mode output LED driver. This driver can be controlled by external signal Phase-Cut ,0-10V to achieve a smooth dimming effect. Features ·Single channel constant voltage output,4A Max ·Wide input voltage of 120VAC ~ 277VAC ·Dimming range of 0.1-100%, and dimming effect smooth, no flicker ·100% output when no dimming signal input, can be used as normal power supply ·Protection: Over load; short circuit; O...

detail
60W 24VDC Triac & 0-10V CV Driver MUP60AT-1W24V-B

60W 24VDC Triac & 0-10V CV Driver MUP60AT-1W24V-B MUP60AT-1W24V-B is a constant voltage mode output LED driver. This driver can be controlled by external signal Phase-Cut, 0-10V to achieve a smooth dimming effect. Features ·Single channel constant voltage output,2.5A Max ·Wide input voltage of 120VAC ~ 277VAC input voltage of 120VAC ~ 277VAC ·Dimming range of 0.5-100%, and dimming effect smooth, no flicker ·100% output when no dimming signal input, can be used as normal power supply ·Prot...

detail
