75W 24VDC 0/1-10V CV Driver EUP75A-1H24V-1
75W 24VDC CV 1-10V Driver EUP75A-1H24V-1
EUP75A-1H24V-1 is a constant voltage mode output LED driver. This driver can be controlled by external signal (0/1-10V active signal, adjustable resistance and PWM signal) to achieve a smooth dimming effect.
Product Features
·Single channel constant voltage output,3.1A Max
·Support 3-in-1 dimming mode( 0/1-10V active signal, adjustable resistance and PWM signal)
·High input voltage of 220VAC ~ 240VAC
·Dimming range of 0-100%, and dimming effect smooth, no flicker
·100% output when no dimming signal input, can be used as normal power supply
·Over load protection; over voltage protection; short circuit protection;Over temperature
·IP20, suitable for indoor LED lighting application
Technical Parameters
| Model | EUP75A-1H24V-1 | |
| Input | Efficiency | >90%@230VAC,Full load |
| Voltage | 220VAC-240VAC | |
| Frequency Range(Hz) | 50/60Hz | |
| Power Factor | ≥0.5@230VAC,Full load | |
| AC Current(max) | 0.9Amax@230VAC | |
| Inrush Current(max) | Cold start,45A@230VAC | |
| Output | Current(mA)/Voltage (VDC) Power(W) | 3.1A/24VDC/74.4W |
| R & N (Max) | 200mVp-p | |
| Channel | 1 | |
| Voltage Accuracy | ±3% | |
| Function | Dimming Type | 0/1-10V active signal, adjustable resistance, PWM |
| Dimming Range | 0.1%-100% Dimming to off | |
| Protection | Short Circuit | Hiccup , recovers after fault condition is removed |
| Over Load | Hiccup , recovers after fault condition is removed | |
| Over Voltage | Hiccup , recovers after fault condition is removed | |
| Others | Working Temp. | -20℃ ~50℃ |
| Storage Temp., Humidity | -40℃~85℃ 20-90%RH | |
| tc | 90℃ | |
| Material | Metal | |
| IP Rating | IP20 | |
| Lifetime | 30,000h@tc:80℃ | |
| Warranty Condition | 3 years | |
| Switch Cycle | >15,000 times | |
| Packing(weight) | Net weight: 412g±5%/PCS; 30PCS/Carton;12.8kg±5%/Carton; Carton Size: 382*222*215mm(L*W*H) | |
| Dimension | 203*54*33mm（L*W*H） | |
