12W 12VDC DALI CV Driver EUP12D-1H12V-0
12W 12VDC 1A*1ch Constant Voltage DALI Driver EUP12D-1H12V-0
EUP12D-1H12V-0 is a constant voltage mode output LED driver and complies with DALI standard protocol IEC 62386. This driver can be connected to DALI main controller or Touch DIM to achieve a smooth dimming effect.
Features
1. Single channel constant voltage output,1A Max
2. Meet DALI protocol IEC 62386
3. Support Touch DIM function
4. Dimming effect smooth, no flicker
5. Overload protection; Over voltage protection
6. IP20, suitable for MR16 and other indoor LED lighting
Technical Parameters
| Model | EUP12D-1H12V-0 | |
| Output | Channels | 1 |
| Voltage | 12VDC | |
| Current | 1A | |
| Power | 12W | |
| Voltage Accuracy | ±3% | |
| R & N (Max) | 120mVp-p | |
| Input | Voltage | 220VAC – 240VAC |
| Frequency | 50/60Hz | |
| Efficiency | >80%@230VAC,full load | |
| PF | >0.5@230VAC,full load | |
| Current | 0.15A@230VAC | |
| Inrush current | Cold start,12A@230VAC | |
| Protection | Short circuit | Close output, recovers automatically after fault removed |
| Over load | Close output, recovers automatically after fault removed | |
| Over temperature | Shut down the output, recovers automatically when temp. back to normal. | |
| Function | Dimming mode | DALI, Touch DIM |
| Others | Dimension | 78*36*29 mm L*W*H |
| G.W | 85g | |
| IP rating | IP20 | |
| Working temp. | -20℃ ~ 50℃ | |
| Relative humidity | 20~90% RH | |
