12-20VDC 2mA DALI group-scene controller DALI-GSC-4
12-20VDC 2mA DALI group-scene controller DALI-GSC-4
Feature
1. Designed to comply with IEC60929/62386
2. Choose group or scene mode via DIP switch
3. Can individually control max.4 groups or scenes
4. Can dim up/down, on/off of any group on the panelㄗOnly for group modeㄘ
5. Can choose different scenesㄗOnly for scene modeㄘ
6. Power supply via DALI bus
Technical Parameter
| Product Name | 12-24VDC 2mA DALI group-scene controller |
| Model | DALI-GSC-4 |
| Power supply | Via DALI signal line |
| Input | 12-20VDC |
| Signal current | 2mA |
| Output | Dimming/Off/On for 4 groups individually (For group control) Switch sceneㄗFor scene controlㄘ |
| Dimension | 44*46*14mm |
| Temperature | 0~60⊥ |
