100W 24VDC 2ch Non-dimmable CV LED Driver UCS100-2H24V-S8

Short Description:

Item No.: UCS100-2H24V-S8
Output Power: 100W

Product Detail

Product Tags

100W 24VDC 2ch Non-dimmable CV LED Driver UCS100-2H24V-S8

UCS100-2H24V-S8 is a constant voltage mode output LED driver. The color temperature can be adjusted through the dip switch,and there are 8 color temperatures to choose from. Color temperature 2700K/3000K/3500K/4000K/4500K/5000K/5500K/6500K

Features

· A channel constant voltage output
· Applicable to indoor LED lights
· Small size, high efficiency, high reliability and long life time
· -20°C~+50°C, working temp
· Protections: over load, over voltage, short circuit protection
· Compliance with CE and ROHS
· 100% Full load aging test
· The warranty period is 5 Years

Technical Parameters

Model	UCS100-2H24V-S8
Input	Efficiency	>92%@230VAC, full load
	Voltage	220VAC-240VAC
	Frequency	50/60Hz
	Power Factor	≥0.95@230VAC, full load
	Current	0.5Amax@230VAC
	THD	<10%@230VAC, full load
	Inrush Current	Cold start,45A@230VAC 280us
	Standby power	<1W
Output	Current/Voltage/Power	4.17A/24VDC/100W
	Channel	2
	Voltage Tolerance	±5%
	No load output voltage	25.2VDC max
	Turn on delay Time	<0.5s, at230Vac (When the light begins to shine)
Protection	Short Circuit	Close output, Automatic recovery after troubleshooting
	Over Voltage	Current down, troubleshooting output normal
	Over Load	Current Reduce, burp, Automatic recovery after troubleshooting
Safety & EMC	Surge	L-N:1KV
	Withstand Voltage	I/P-O/P: 3570VAC/1min/5mA
	Safety standards	EN61347-1,EN61347-2-13
	EMC Eission	EN55015, EN61547
	EMC Immunity	EN61000-3-2, 3; EN61547
Others	Working Temp.	-20°C~+50°C
	Storage Temp.; Humidity	-40°C~85°C, 20-90%RH
	Tc	90°C
	Material	PC
	IP Rating	IP20
	Lifetime	50,000h@tc:90°C
	Warranty Condition	5 Years
	Switch Cycle	>25,000 times
	Packing Size	Net weight: 175g±5%/PCS; 50PCS/Carton; 9.25kg±5%/Carton; Carton Size: 513380150mm(LWH)
	Dimension	3123018mm(LWH)
