100-900mA*4ch DMX512/RDM Constant Current Decoder PX709

100-900mA*4ch DMX512/RDM Constant Current Decoder PX709

Features
· Meet DMX512/1990, RDM/2009 international standard protocol
· 4 output channels, output current 100 to 900 mA per channel
· Can easily set DMX address by button
· Can easily set output current each channel
· With the light color selected mechanism, and be able to control
the light with 1~4 colors
· 8 Bit /16 Bit level brightness, full-color control
· For customer setup and use easily, the default address code is 1
· Address setting become brightness setting when DMX signal isn’t connected
· Suitable for buildings, hotels, KTV, home and other places

Technical Parameters
Channels: 4 channels
Input Voltage: 12-50V DC
Output Voltage: 1-42V DC
Output Current:100-900mA per channel (The error is 7% within 200mA)
Output Power: 37.5W*4CH MAX. 150W
Protection: Short-circuit protect,Over current protect, Over temp protect
Dimension:116(L)×54(W)×35(H) mm
N.G.:230g
Operation Temperature:-20 – 50 ℃
